4MP 37x Zoom(6.5~240mm) and 640x512 Thermal Bi-spectrum Network NDAA PTZ Camera

4mp 37x zoom (6.5 ~ 240mm) na 640x512 thermal bi - spectrum Network


> Umuyoboro 1 Ubushyuhe na Video Video Stream.
> Aderesi ya IP kuri chip nyamukuru, ihamye kuruta ibicuruzwa bibiri bya IP.
> Horizontal 360 ° kuzunguruka, kwihuta kugera 0.1 ° ~ 30 ° / s
> Vertical - 90 ° ~ + 90 °, kwihuta kugeza 0.1 ° ~ 15 ° / s
> Ir Intera 60m, ip67 ibimenyetso byamazi
Kamera
> 1 / 1.8 "SOY Exmour CMOS SENSOR.
> Imbaraga zikomeye 37x optique zoom (6.5 ~ 240mm).
> Max. 4mp (2688x1520) gukemura
> Shigikira ibikorwa bitandukanye bya IV
> Shigikira defogi ya elegitoronike & optique defog
> Hamwe na Novatek Imikorere minini
Kamera
> 640x512 gukemura, kumva neza kwiyumvisha
> 12Um Pixel.
> 25mm lens itunganijwe neza (13mm / 19mm / 35mm kubishaka)
> SG - PTZ4037NK - 6T25T irashobora gushyigikira imikorere yubushyuhe



    Gukuramo

    Ibisobanuro birambuye

    Urwego

    Icyitegererezo

    SG - PTZ4037NK - 6T25

    SG - PTZ4037NK - 6T25T

    Kamera

    Sensor

    		IshushoYatunganijweVOxMicrobolometer
    Imyanzuro640 x512
    Ingano ya Pixel12μm
    Intera meza8~ 14μm

    Lens

    		Uburebure bwibanze25mm (13mm / 19mm / 35mm lens kubihitamo)
    F AgaciroF1.0
    IntegoAtherizelize, kwibanda - kubuntu
    Inguni17.6 ° X14.1 ° (32.9° ×26.6°/ 22.9° ×18.4°/ 12.5°x10°bidashoboka)

    Vingego

    		Imyanzuro50hz: 25fps@(1280 × 1024, 1280 × 720)

    60hz: 30fps@(1280 × 1024, 1280 × 720)

    Ibara rya pseudoInkunga: Full Ashyushye, FulGurite, Icyuma gitukura, Icyuma gishyushye, Ubuvuzi, ARCTIC, Umukororombya 1, Umukororombya 1, TIntbow 2, TIntbow 2, Tint
    IvsUmuyoboroWire, Kureka kurengana, kwinjira
    FKumenya IreSUPportSUPport

    Ubushyuhe

    		Gupima ubushyuheN / aInkunga
    MkubuntuInteraN / aHasi- T Mode:- 20℃~ 150℃,

    Hejuru - t Mode: 0℃~ 550℃

    MByoroshyeN / a± 4 ℃ cyangwa ± 4% (Fata indangagaciro nini)
    MkubuntuIbikoreshoN / a12 Ibibanza /12 agaces / 12imirongo / Max. & Avg. & Min. Temp kuri ecran / max. Amabwiriza 12 / Isesengura
    IbikorwaN / aTigger relay hanze, snapshot, inyandiko, PTZ guhamagara, hejuru& Hasi TeDepite.
    Kamera

    Sensor

    		Ishusho1 / 1.8"Sony Starvis itera imbere scan cMos
    Pigiseli nzizaHafi. 4.17 Megapixel

    Lens

    		Uburebure bwibanze6.5mm~240mm, 37x Optique
    ApertureF1.5~F4.8
    Umwanya wo kurebaH:61.8°~ 1.86°, V:37.2°~ 1.05°,D:69°~ 2.1°
    Intera ya hafi1m~1.5m (Ubugari~Tele)
    Zumuvuduko wa oomHafi.4.0s (optique yagutse ~ tele)
    Dori intera

    (Muntu)

    		KumenyaItegerezeMenyaMenya
    3,311m1,314m662m331m

    Vingego

    		KwikuramoH.265 / H.264 / H.264h / Mjpeg
    Ubushobozi bworoshye3 imigezi
    Imyanzuro50hz: 25/ 50FPS@4Mp(2688x1520)

    60hz: 30/ 60FPS@4Mp(2688x1520)

    Video Bit Igipimo32Kbps ~ 16Mbps
    AUdioAAC / MP2L2
    Ibyabaye rusangeMotion, Tamper, ikarita ya SD, umuyoboro
    IvsDOGHWIRE, utwotinda wambukiranya uruzitiro, ikintu cyatereranywe, byihuse - Gutererana, Gutererana, gukusanya ibintu, imbaga yabuze
    S / n≥55DB (AGC,Uburemere kuri)
    KumurikaIbara:0.005lux / F1.5;B / w:0.00055lux / F1.5
    NoiseRkurema2D/ 3D
    Uburyo bwo kwerekanaAuto, Aperture yibanze, funga icyambere, reba imyambarire,Imfashanyigisho
    Indishyi ZifataInkunga
    Umuvuduko1/1 ~ 1/30000s
    BlcInkunga
    HLCInkunga
    WdrInkunga
    Kuringaniza YeraAuto, intoki, mu nzu, hanze,ATW, itara rya sodium,Umuhanda lamp,Karemano,Imwe Gusunika
    Umunsi / nijoroAmashanyarazi, ICR (Auto / Igitabo)
    IR Intera60m
    Uburyo bwo kwibandaAuto, imfashanyigisho, igice cyimodoka, auto yihuta, yihuta yimodoka, gusunikaAF
    DefogInkunga
    OPTICAL DEFOGInkunga
    FlipInkunga
    EisInkunga
    Zoom zoom16x
    Ptz
    Pan / TISTPan: 360 °; TOLT: - 90 ° ~ 90 °
    Umuvuduko wa PanItegurwa, Pan: 0.1 °~30 ° / s; Predet Umuvuduko: 30 ° / s
    ImpingaUmuvudukoItegurwa, Pan: 0.1 °~15 ° / s; Preset Umuvuduko: 15 ° / s
    PRESETS256
    IrondoAmarondo 8, kugeza kuri 32 prestures kuri buri rondo
    Umurongo wo gusikana5
    IcyifuzoKoresha Preset / Scan / Urugendo / Pan Scan
    Imbaraga zo hejuruKoresha Preset / Scan / Urugendo / Pan Scan
    Imikorere rusange
    KwikuramoH.265 / H.264 / H.264h / Mjpeg
    UbubikoCUbushoboziIkarita ya TF (256 GB), FTP, NAS
    UmuyoboroProtocolOnvin, http, https, iPv4, iPv6, RTSP, DDNS, RTP, TCP, UDP
    ImikoranireOnvinif, GB / T28181, Cgi

    Imigaragarire

    		ImigaragarireDc24 3a
    EthernetRJ45 (10Base - T / 100Base - TX)
    Audio I / O.1/1
    GutabazaI / o1/1
    Rs4851, fasha pelco - d protocole
    Imiterere y'akazi- 40 ° C.~+65 ° C.(<90%RH)
    AmashanyaraziDC24V /3A ±15%
    Kunywa amashanyaraziMax. 20W
    Ikizamini cya VibrationInshuro 10 - 55Hz, 1 octave / min, amplitude 0.35mm, Ibizamini bitatu muri X, PTZ iri mubice bitari bisanzwe, GB 16796 - 2009
    Urwego rwo kurengeraIp67; TV 4000V Kurengera, GB / T17626.5
    Ibipimo (l *W*H)332(mm) ×245(mm) ×276(mm)
    Uburemere7.5kg
