1280x1024 Ubushyuhe + 4MP 60x Optique Zoom Bi - Spectrum Umutwaro uremereye Precional Network Network Network Network
|
Icyitegererezo |
SG - PTZ4060NIO2 -12T50350 |
SG - PTZ4060NIO2 -12T25225 |
||||
|
Ubushyuhe |
||||||
|
Sensor |
Ishusho |
Ibiti bya Vox Microbolometero |
||||
|
Imyanzuro |
1280 × 1024 |
|||||
|
Ingano ya Pixel |
12μm |
|||||
|
Intera meza |
8 ~ 14μm |
|||||
|
Netd |
≤50Mk @ 25 ℃, f # 1.0 |
|||||
|
Lens |
Uburebure bwibanze |
50 ~ 350m lens ya moteri |
25 ~ 225m lens ya moteri |
|||
|
Aperture |
F0.95 ~ F1.4 |
F1.0 ~ F1.5 |
||||
|
Umwanya wo kureba |
17.5 ° × 14.0 ° ~ 2.5 ° × 2.0 ° (W ~ T) |
34.2 ° × 27.6 ° ~ 3.9 ° × 3.1 ° (W ~ T) |
||||
|
Kuzamura |
7x |
9x |
||||
|
Zoom zoom |
4x |
4x |
||||
|
Urwego rwo kurengera |
IP66 Amata yikirahure cya 1 cya lens. |
|||||
|
Video |
Kwikuramo |
H.265 / H.264 / H.264h |
||||
|
Snapshot |
JPEG |
|||||
|
Ibara rya pseudo |
Inkunga: Gushyushya, Bishyushye Bishyushye, Icyuma gitukura, umukororombya 1, Umukororombya, Umukororombya 2, Umukororombya 2, Fursion, Blusity Umutuku, Amber, TITCTIC |
|||||
|
Imigezi |
Umugezi nyamukuru: 25fps @ (1280 × 1024) Sub Stream: 25fps @ (640 × 512), 25fps @ (352 × 288) |
|||||
|
Umuyoboro |
Umuyoboro |
IPV4 / IPV6, HTTP, HTTPS, QOS, FTP, UPNP, DHCS, RTP, DHCP, PPPOE, 302.1x, ip filteri |
||||
|
Imikoranire |
ONVIF Umwirondoro S, Fungura Api, SDK |
|||||
|
Max. Guhuza |
20 |
|||||
|
Ubwenge |
Ibyabaye bisanzwe |
Kumenya icyerekezo, gutahura amajwi, amakimbirane ya IP adresti, uburyo butemewe n'amategeko, kubika anomaly |
||||
|
IV |
Shigikira imikorere yubwenge:Umuyoboro,Kumenya uruzitiro, kwinjira, Gutererana. |
|||||
|
Kumenyekanisha umuriro |
Inkunga |
|||||
|
Ubushobozi bwo kubika |
Ikarita ya Micro SD, kugeza kuri 256G |
|||||
|
Vizale |
||||||
|
Sensor |
Ishusho |
1 / 1.8 "Sony Starvis aratera imbere CMOS |
||||
|
Pigiseli nziza |
Hafi. 4.17 Megapixel |
|||||
|
Lens |
Uburebure bwibanze |
20mm ~ 1200mm, 60x Optique zoom |
||||
|
Aperture |
F2.92 ~ F11.37 |
|||||
|
Umwanya wo kureba |
H: 22.06 ° ~ 0.37 °, V: 12.21 ° ~ 0.21 °, D: 25.21 ° ~ 0.23 ° |
|||||
|
Intera ya hafi |
2m ~ 50m (yagutse ~ tele) |
|||||
|
Umuvuduko wa zoom |
<10s (optique yagutse ~ tele) |
|||||
|
Dori intera (Muntu) |
Kumenya |
Itegereze |
Menya |
Menya |
||
|
16,650M |
6.607m |
3,330m |
1,665m |
|||
|
Video |
Kwikuramo |
H.265 / H.264B / H.264M / H.264.h / Mjpeg |
||||
|
Ubushobozi bworoshye |
Imigezi 3 |
|||||
|
Imyanzuro |
Imigezi nyamukuru: 50 / 60fps @ 2688 × 1520; 50 / 60fps @ 1920 × 1080; 50 / 60fps @ 1280 × 720 Sub Stream1: 50 / 60fps @ 704 × 576; 50 / 60fps @ 352 × 288; Sub Stream2: 50 / 60fps @ 1920 × 1280; 50 / 60fps @ 1280 × 720; 50 / 60fps @ 704 × 576 |
|||||
|
Video Bit Igipimo |
32Kbps ~ 16Mbps |
|||||
|
Amajwi |
AAC (8 / 16KHZ) / MP2L2 (16Khz) |
|||||
|
Umuyoboro |
Umuyoboro |
IPV4, IPV6, HTTP, HTTPS, TCP, UDP, RTP, DHCP, DNSP, DNSP, DNSP, DNSP, QOS, QOS, BonSour |
||||
|
Api |
Onvin, http api, sdk |
|||||
|
Urubuga |
Ni ukuvuga, inkombe, firefox, chrome |
|||||
|
Umukoresha |
Abakoresha bagera kuri 20, urwego 2: Umuyobozi, Umukoresha |
|||||
|
Ububiko |
Micro SD / SDHC / SDXC Ikarita (kugeza kuri 1TB) Ububiko bwa Edge, FTP, NAS |
|||||
|
Multicast |
Inkunga |
|||||
|
Ibyabaye rusange |
Icyerekezo, tamper, ikarita ya SD, umuyoboro |
|||||
|
Ivs |
DOGHWIRE, utwotinda wambukiranya uruzitiro, ikintu cyatereranywe, byihuse - Gutererana, Gutererana, gukusanya ibintu, imbaga yabuze |
|||||
|
Intego yo gutandukanya |
Umuntu / imodoka |
|||||
|
S / n |
≥55DB |
|||||
|
Kumurika |
Ibara: 0.05lux / F2.92; B / W: 0.005Lux / F2.92 |
|||||
|
Kugabanya urusaku |
2D / 3D / Kugabanya urusaku |
|||||
|
Uburyo bwo kwerekana |
Auto, Imbere Yibanze, Funga Icyambere, Koresha Ibyingenzi, Imfashanyigisho |
|||||
|
Indishyi Zifata |
Inkunga |
|||||
|
Umuvuduko |
1/1 ~ 1/30000 |
|||||
|
Blc |
Inkunga |
|||||
|
HLC |
Inkunga |
|||||
|
Wdr |
Inkunga |
|||||
|
Kuringaniza Yera |
AUTO, UNUAL, MUTOOR, Hanze, AT, Amatara ya Sodium, itara ryumuhanda, karemano, gusunika |
|||||
|
Umunsi / nijoro |
ICR (Auto / Igitabo) |
|||||
|
Uburyo bwo kwibanda |
Auto, imfashanyigisho, igice cya auto, inshuro imwe af |
|||||
|
Defog |
Inkunga |
|||||
|
Optique defog |
Inkunga, 750nm ~ 1100nm umuyoboro ni optique defogi |
|||||
|
Ubushyuhe bwa haze |
Inkunga |
|||||
|
Flip |
Inkunga |
|||||
|
Eis |
Inkunga |
|||||
|
OIS (Sprique ishusho nziza) |
Inkunga (ON / OFF) |
|||||
|
Zoom zoom |
16x |
|||||
|
Isafuriya |
||||||
|
Pan / TIST |
Pan: 360 ° kuzunguruka; TOLT: - 90 ° ~ + 90 ° |
|||||
|
Umuvuduko wa Pan |
Ishirwaho, Pan: 0.01 ° ~ 180 ° / s |
|||||
|
Umuvuduko |
Itegurwa, Pan: 0.01 ° ~ 100 ° / s |
|||||
|
ICYEMEZO CY'ABANYARWANDA - Umwanya |
0.003 ° |
|||||
|
Umwanya Ukuri |
0.003 ° |
|||||
|
Gukemura Umuvuduko Wihuta |
0.001 ° / s |
|||||
|
Preset |
256 |
|||||
|
Urugendo |
8, kugeza kuri 32 plassets kuri buri rugendo |
|||||
|
Scan |
5 |
|||||
|
Icyitegererezo |
5 |
|||||
|
Parike |
Press / Urugendo / Scan / Icyitegererezo |
|||||
|
Igikorwa giteganijwe |
Press / Urugendo / Scan / Icyitegererezo |
|||||
|
Imbaraga - Kureka kwibuka |
Inkunga |
|||||
|
Snap |
Inkunga |
|||||
|
Ugereranije p / t to yoom |
Inkunga |
|||||
|
Gushyushya / Umufana |
Ihuriweho, auto / imfashanyigisho |
|||||
|
Wiper |
Ihuriweho, imfashanyigisho / iteganijwe |
|||||
|
Imigaragarire |
||||||
|
Imigaragarire |
Inkunga, GND |
|||||
|
Ethernet |
1x rj45 (10 / 100mbps wenyine - Ibyamamare bya Etherive) |
|||||
|
Audio I / O. |
1/1 (kuri kamera igaragara gusa) |
|||||
|
Imenyesha i / o |
7/2 |
|||||
|
Rs485 |
1, gushyigikira pelco - d protocole |
|||||
|
Rusange |
||||||
|
Amazi |
Ip66 |
|||||
|
Imbaraga |
DC48, isanzwe 30w, max 180w |
|||||
|
Ubushuhe |
<90%, Non - Condansing |
|||||
|
Ubushyuhe bwakazi |
- 40 ℃ ~ + 60 ℃ / 22 ℉ ~ 140 ℉ |
|||||
|
Ibipimo (l * w * h) |
590mm * 835mm * 524.5mm |
|||||
|
Uburemere |
Hafi. 88kg |
|||||
|
Kurinda |
Ruswa - Imyenda irwanya ihura na societe ishyize mu gaciro: ASTM B117 / ISO9227 (Amasaha 2000) TV 6000V, Kurinda Uburinzi bwa Voltage |
|||||
